1. Closed and environmentally friendly body
The whole machine casing is closed to reduce dust flying caused by material leakage during operation and meet environmental protection requirements.
2. Reduce the entire process of material crushing, feeding, transportation, and unloading to reduce damage to the granular material itself and reduce the yield rate.
3. Various conveying forms
It can be used in Z-type, C-type, ZC mixed type, straight-line type, etc. to suit various occasions.
4.Multi-point feeding/unloading
It can automatically unload materials at a single point or multiple points, and is suitable for feeding multiple warehouses in a row.
5. Even feeding, less overflow and leakage
It can be equipped with a vibrating feeder and inflow-type uniform speed feeding.
6. Space saving and flexible layout
Horizontal, heavy and straight combined conveying, compact structure.
7. User-tailored
It can be transported horizontally up to 100 meters and lifted straight up to 60 meters.
|
Lightweight |
Model | Conveying capacity(m/h) | Hopper capacity(L) | Running speed | Lift height | Horizontal length | Motor Power(kW) |
| MFZD-1L | 3 | 1 | 9-11m/min | ≤10m | ≤10m | 0.75-1.5 | |
| MFZD-1.8L | 5.5 | 1.8 | 0.75-3 | ||||
| MFZD-1.8L(More) | 4.3 | 1.8 | 1.5-3 | ||||
| MFZD-3.8L | 11 | 3.8 | 1.5-3 | ||||
| MFZD-3.8L(More) | 8 | 3.8 | 1.5-3 | ||||
| MFZD-4.8L | 14 | 4.8 | 1.5-4 | ||||
| MFZD-5.8L | 18 | 5.8 | ≤15m | ≤15m | 1.5-5.5 | ||
|
Heavy duty |
Model | Conveying capacity(m/h) | Hopper capacity(L) | Running speed | Lift height | Horizontal length | Motor Power(kW) |
| MFZD-2L | 6 | 2 | 9-11m/min | ≤50m | ≤100m | 0.55-11 | |
| MFZD-3L | 8 | 3 | |||||
| MFZD-5L | 12 | 5 | |||||
| MFZD-7L | 15 | 7 | |||||
| MFZD-10L | 19 | 10 | |||||
| MMFZD-13L | 25 | 12 | |||||
| MFZD-20L | 35 | 20 | |||||
| MFZD-30L | 50 | 30 |
