1. Use imported touch screen control instruments, weighing sensors, and pneumatic actuating components, with high measurement accuracy and stable performance;
2. Automatic error correction, positive and negative difference alarm, fault source diagnosis and other functions;
3. The sealed bag clamping mechanism, the door panel with no residue structure, and the bag clamping and powder return device have a residue-free powder return design to prevent material residue and
4. All parts in contact with the material are made of stainless steel and have a long service life.
| Product name | Model | Weighing range (kg/bag) | Maximum working capacity (packs/minute) | Accuracy | Gas source, gas consumption | Power | Installation height(mm) |
| Gravity packaging scale (single scale) | SBZZ-50-C | 20-50 | 7-9 | ≤±0.2%FS | 0.4-0.6MPa
1.5m²/h |
AC220V 50Hz
0.15KW |
3180 |
| Gravity packaging scale (double scale) | SBZZ-50- SC |
5-50 |
Granules：10-12
Concentrate：8-9 |
≤±30g |
0.4-0.6MPa
1.5m³/h |
AC380V 50Hz
0.45KW |
3500 |
